Job - Geraldton Grammer School
Subcontractor - Glass Co WA Pty Ltd, 25 Bradford St GERALDTON (AGWA/AWA ACCREDITED)
(Note all existing framing on site is ALSPEC COMMERCIAL SYSTEMS)
ALSPEC Commercial Systems v AWS
System equivalent to GERALDTON Grammer School NEW GYMNASIUM project
Main Frame - ALSPEC 150mm FLUSHGLAZE v AWS 606 Series
Sliding Windows - ALSPEC Viemax V AWS 662 Series
Hinged Doors - ALSPEC SWAN EVO v AWS 50 Series
All equivalents match or are greater than in structural strength and water ratings for this project.
WARRANTY PERIODS
Powdercoating - 15 Years
Aluminium (Manufacture & Installation) - 6 Years
Glazing - 6 Years
Main Framing - Typical DW1
ALSPEC 150mm FLUSHGLAZE
https://www.alspec.com.au/hunter-evo-150mm-single
The Hunter Evo 150mm Single Flush Glazed Framing is the most versatile and flexible of the Alspec® Commercial Framing Systems. Available in a frame depth of 150mm x 50mm, it is ideal for shopfronts.
With it's straight cuts and flush glazing the Hunter Evo not only looks good, but is easy to fabricate and easy to install. Suitable for a range of single glass thickness options to address the most demanding energy requirements. With self draining sub sills it also solves water leakage problems. The system can be internally or externally glazed along with incorporating the flexibility and appeal of gently curved or faceted frame installations. The Hunter Evo also provides a seamless interface with Alspec's® extensive product offer.
COMMERCIAL SLIDING WINDOWS - Typical W5
ALSPEC VIEW-MAX
https://www.alspec.com.au/view-max-sliding-window/
The View-Max window offers unparalleled levels of flexibility by allowing designers, architects, the choice of 76mm (Derwent) or 101.6mm and 150mm (McArthur) framing to cater for both the slimline applications and those of a more robust commercial design. The View-Max window offers the flexibility of single and double glazing options. The View-Max integrates a number of design initiatives unique to Alspec such as the proprietary locking, roller and drainage systems.
Key Features • Commercially designed with sliding & double-hung options to suit 76mm, 101.6mm & 150mm • Developed specifically for multi-storey residential, schools and architecturally designed housing • 4mm up to 11mm monolithic glass and up to 16mm double glazed units. • Superior thermal and acoustic performance (refer to test reports) • Superior weather performance
Commercial Hinged Doors - Typical DW4
ALSPEC SWAN EVO COMEMRCIAL DOOR - https://www.alspec.com.au/swan-evo-45mm-commercial-door
The Alpsec® Swan Evo™ 45mm Commercial Door is a versatile shopfront door that is easy to fabricate and install. Suitable for a wide range of applications, the Swan Evo™ can be used in hinged, pivoted or sliding configurations. The Swan Evo™ integrates seamlessly with the Alspec® commercial framing systems.
Featuring a new and improved clamping spigot set, for superior performance and easy fitment, integrated heal and toe block and captive glazing option, the Swan Evo™ provides the ideal solution where superior operation and performance is required. Glazing could not be simpler with the colour coded wedges from standard Alspec® systems being utilised to deal with the many diverse glass options.
AWS 50 Series Door
https://www.awsaustralia.com.au/elevatealuminium/commercial-door-single-side-beaded
